GR5 Titanium Plates

• High strength and lightweight:The annealed tensile strength is ≥ 895MPa, the yield strength is ≥ 825MPa, the elongation is ≥ 10%, the density is only 4.43g/cm ³, and the specific strength is 2.5 times that of stainless steel. It can meet the high stress structural requirements while being lightweight. After solid solution aging treatment, the strength can reach 1100MPa, suitable for extreme working conditions such as aircraft engine blades.
• Process and environmental adaptability:Support forging, cold rolling, hot rolling, and welding processing, with welding joint strength reaching over 90% of the base metal, suitable for the manufacturing of complex structural components.

• Aerospace: Aircraft landing gear, turbine discs, and combustion chamber shells of aerospace engines maintain structural integrity in high temperature and high pressure environments.
• Medical field: Artificial joints, dental implants, excellent biocompatibility, and stable integration with human bones.

Automotive industry: Lightweight chassis components, exhaust system, reducing vehicle weight while improving fuel efficiency.

Technical Parameter

• Chemical composition: Ti-6Al-4V (Al 5.5-6.75%, V 3.5-4.5%), in accordance with ASTM B265 and GB/T 3621 standards;
• Typical specifications: thickness 0.5-50mm, width ≤ 2000mm, surface can be customized with acid wash (Ra ≤ 3.2 μ m) or glossy surface;
• Certification support: ISO 9001 certification.

Quality Assurance

• Adopting vacuum consumable arc furnace melting+multi-directional rolling process, the grain size is uniform and dense, and the entire process passes ultrasonic testing and third-party mechanical property testing.
